Temperature range: |
(MB 6) 100 to 600°C
(MB 8) 200 to 800°C
(MB 13) 100 to 1300°C
(MB 25) 400 to 2500°C
(Other MB on request)
|
Sub range: |
The plus instruments are user adjustable with minimum span of 51°C |
Spectral Range: |
5.14 μm |
IR Detector: |
Thermopile |
Data handling: |
Digital |
Optics: |
Zinc-Sulfide lens (ZnS) |
Power Supply: : |
24 V DC (10 to 30 V) |
Power Consumption: |
max. 20 mA |
Analog Output: |
4 to 20 mA (linear) |
Load: |
max. 700 Ω at 24 V (max. 100 Ω at 12 V) |
Parameters |
Adjustable on the pyrometer: Emissivity, exposure time. |
Emissivity ε: |
0.2 ... 1 adjustable |
Exposure Time t90: |
0.08 s; adjustable in the pyrometer: 0.5 s; 1 s; 2 s; 5 s, |
Measurement Uncertainty:
Dependent on object temperature T and
ambient temperature Tamb (ε= 1, t90= 1s)
|
T < 1300°C: 0.6% (IN 5/5-Lplus: 0.8%) of reading in °C or 2°C (Tamb=15 to 30°C) *)
1% of reading in °C or 1.5°C (Tamb=0 to 15 or 30 to 63°C) *)
T=1300 to 1800°C: 0.8% of reading in °C (Tamb=15 to 30°C)
1.2% of reading in °C (Tamb=0 to 15 or 30 to 63°C)
T=1800 to 2500°C: 1% of reading in °C (Tamb=15 to 30°C)
1.4 % of reading in °C (Tamb=0 to 15 or 30 to 63°C)
*) Whichever value is greater. The instrument must be at a constant ambient temperature for a minimum of 15 minutes (30 min for IN 5/5-L plus for 200 to 1300°C at Tamb = 0 to 15 or 30 to 63°C) and has to be connected to the power supply.
|
Repeatability: (ε = 1, t90= 1 s)
|
0.3% of reading in °C or 0.6°C
(Whichever value is greater. The instrument must be at a constant ambient temperature for a minimum of 15 min. (30 min for IN 5/5-Lplus for 200...1300°C at Tamb= 0 to 15 or 30 to 63°C)
|
Noise Equivalent Temperature Difference
(NETD): (ε = 1, Tamb= 23°C) |
At t90= 80 ms: 0.7°C (at 110°C measuring temperature)
At t90= 1 s: 0.4°C (at 110°C measuring temperature) |
Ambient Temperature: |
IN 5/5: 0 to 70°C |
Storage Temperature: |
-20 to 70°C |
Housing: |
Stainless steel |
Weight: |
410g |
Protection class: |
IP65 (DIN 40050) |
Relative humidity: |
Non condensing conditions |
CE-label: |
According to EU directives about electromagnetic immunity |
